Introduction:
1. FSB strong acid alkali centrifugal pump anti resistant PTFE TEFLON chemical pump is reasonable design, compact structure, reliable performance, easy to use and saving energy.
2. Applied to convey strong acid, strong alkali, oxidant, corrosive medium (forbid to transit medium likely to crystallize) with physical property similar to water.
3. Wet parts are made of fluorine plastic alloy through reasonable design, mold pressing, machining, with advantages of strong corrosion resistance ability, high mechanical strength, non aging, no toxin decomposed.
4. It is widely used in the fields of chemical industry, petrol, medicine, pesticide, dye, smelting, paper making, plating, and food, etc.
Product details:
| Working Principle: | Centrifugal, full plastic pump head |
| Main applications: | Chemical |
| Driver: | Electric motor |
| Power Specs: | 220V, 240V, 380V, 400V, 415V, 440V, 50/60Hz |
| Max.permissible fluid temperature: | 100°C(212°F) |
| Type of connection: | Flange |
| Installation position: | Horizontal |
| Casing parts material: | PTFE, Teflon, UHMWPE, F46, F26 |
| Shaft seal type: | Mechanical seal |
| Maximum drive rating: | 75KW(100HP) |
| Maximum caliber: | 200mm(8inch) |
| Maximum discharge-side pressure: | 0.8MPa(8bar) |
| Maximum head: | 80m(262.4ft) |
| Flow rate range: | 1.5-400m3/h(6.6-1760US.GPM) |
Performance data:
| Model | Capacity (m3/h) | Head (m) | Inlet (mm) | Outlet (mm) | Power (KW) | Speed (r/min) | Efficiency (%) |
| 25FSB-10L | 1.5 | 10 | 25 | 20 | 2.2 | 2900 | 29 |
| 25FSB-18L | 3.6 | 18 | 25 | 20 | 2.2 | 2900 | 27 |
| 40FSB-15L | 10 | 15 | 40 | 32 | 3 | 2900 | 40 |
| 40FSB-20L | 10 | 20 | 40 | 32 | 3 | 2900 | 42 |
| 40FSB-30L | 10 | 30 | 40 | 32 | 3 | 2900 | 38 |
| 40FSB-40L | 10 | 40 | 40 | 32 | 4 | 2900 | 35 |
| 40FSB-50L | 10 | 50 | 40 | 32 | 5.5 | 2900 | 33 |
| 50FSB-20L | 15 | 20 | 50 | 40 | 4 | 2900 | 51 |
| 50FSB-25L | 15 | 25 | 50 | 40 | 4 | 2900 | 49 |
| 50FSB-30L | 15 | 30 | 50 | 40 | 4 | 2900 | 44.5 |
| 50FSB-40L | 15 | 40 | 50 | 32 | 5.5 | 2900 | 35 |
| 50FSB-50L | 15 | 50 | 50 | 32 | 7.5 | 2900 | 33 |
| 65FSB-32L | 29 | 32 | 65 | 50 | 5.5 | 2900 | 57 |
| 65FSB-40L | 29 | 40 | 65 | 40 | 7.5 | 2900 | 53 |
| 65FSB-50L | 29 | 50 | 65 | 40 | 11 | 2900 | 46 |
| 80FSB-20L | 50 | 20 | 80 | 65 | 7.5 | 2900 | 69 |
| 80FSB-30L | 50 | 30 | 80 | 65 | 7.5 | 2900 | 64 |
| 80FSB-34L | 50 | 34 | 80 | 65 | 11 | 2900 | 64 |
| 80FSB-38L | 50 | 38 | 80 | 50 | 11 | 2900 | 60 |
| 80FSB-50L | 50 | 50 | 80 | 50 | 15 | 2900 | 53 |
| 80FSB-80L | 50 | 80 | 80 | 50 | 22 | 2900 | 36 |
| 100FSB-32L | 100 | 32 | 100 | 80 | 18.5 | 2900 | 70 |
| 100FSB-40L | 100 | 40 | 100 | 80 | 22 | 2900 | 70 |
| 100FSB-50L | 100 | 50 | 100 | 65 | 30 | 2900 | 62 |
| 125FSB-32L | 200 | 32 | 125 | 80 | 30 | 2900 | 72 |
| 125FSB-50L | 200 | 50 | 125 | 100 | 45 | 2900 | 64 |
| 150FSB-32L | 200 | 32 | 150 | 100 | 30 | 1450 | 77 |
| 150FSB-50L | 200 | 50 | 150 | 100 | 55 | 1450 | 75 |
| 200FSB-32L | 400 | 32 | 200 | 150 | 55 | 1450 | 81 |
| 200FSB-50L | 400 | 50 | 200 | 150 | 75 | 1450 | 79 |
